Forklift
Electric Forklift
Model:WX
Design standard: ISO
Lifting capacity: 500kg-3500kg
Lifting Height: 90mm-3000mm
Reference price 1500usd to 6000usd
Introduction
Forklifts are industrial transport vehicles, which refer to various wheeled transport vehicles that are used for loading, unloading, stacking and short-distance transportation of palletized goods. The International Organization for Standardization ISO/TC110 is called industrial vehicles. It is often used for the transportation of large items in warehouses and is usually powered by a fuel engine or battery.
The technical parameters of a forklift are used to indicate the structural characteristics and working performance of the forklift. The main technical parameters are: rated lifting capacity, load center distance, maximum lifting height, mast inclination angle, maximum driving speed, minimum turning radius, minimum ground clearance, wheelbase, wheelbase, etc.
Parameters
| Model(Forklift) | CPD05 | CPD10 | CPD15 | CPD18 | CPD20 | CPD25 | CPD30 | CPD35 |
| Power supply | Storage battery | |||||||
| Load capacity(kg) | 500 | 1000 | 1500 | 1800 | 2000 | 2500 | 3000 | 3500 |
| Load center distance (mm) | 500 | |||||||
| Operator type | Sit down | |||||||
| Forklift length (mm) | 2520 | 3170 | 3170 | 3200 | 3380 | 3380 | 3630 | 3630 |
| Width (mm) | 742 | 900 | 900 | 1050 | 1150 | 1150 | 1220 | 1220 |
| Wheelbase(mm) | 885 | 1180 | 1180 | 1335 | 1515 | 1515 | 1680 | 1680 |
| Front suspension distance (mm) | 220 | 340 | 340 | 483 | 483 | 483 | 490 | 490 |
| Rear distance (mm) | 670 | 890 | 890 | 920 | 950 | 950 | 980 | 980 |
| Min height off ground (mm) | 90 | 90 | 90 | 110 | 135 | 135 | 145 | 145 |
| Max lifting height (mm) | 2000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| Fee lifting height (mm) | 80 | 80 | 80 | 170 | 170 | 160 | 160 | |
| Empty drive speed (Km/h) | 15 | |||||||
| Self weight (kg) | 820 | 1850 | 2000 | 3500 | 4050 | 4250 | 4950 | 5600 |
| Wheel drive number | 2×2 | |||||||
| Tyre type | Solid tyre | |||||||
| Brake type | Hydraulic pedal | |||||||
| Parking brake | Machinery-manual type | |||||||
| Min turn radius (mm) | 1200 | 1500 | 1500 | 1950 | 2050 | 2050 | 2200 | 2200 |
| Battery capacity V/Ah | 48/140 | 48/300 | 48/300 | 48/400 | 48/500 | 48/500 | 80/500 | 80/500 |
| Drive motor (power) | 2 | 4 | 4 | 5 | 11 | 11 | 16.6 | 16.6 |
| Pump motor power (kw) | 2.2 | 5.5 | 5.5 | 8.6 | 12 | 12 | 12 | 12 |
